Four Shaft Fully Automatic Cast PVC Cling Film Machine 1800mm

Model Number : TL-115-2350

Total installed power(kw) : 250

Price : USD310000-USD420000

Model(mm) : TL-115-2350

Design line speed(m/min) : 200

Thickness of finished film(mm) : 0.01-0.015

Screw diameter(mm) : 115

Delivery Time : 120 working days

Width of die(mm) : 2350

Max extrusion capacity(kg/h) : 260-290

Brand Name : TL

Overall diamensions(L*W*H) : 17*7.5*4

MOQ : 1 set

Width of die : 2350mm

Payment Terms : T/T,L/C

Width of finished film(mm) : 1800(300*6 rolls)

Packaging Details : PE stretch film

L/D ratio of screw : 30:1

Weight(T) : 38

Place of Origin : China

Max extrusion capacity : 260-290kg/h

Total installed power : 250kw

Contact Now

Product Application

This machine is design for producing self-adhesive PVC cling film by plasticizing extrusion of PVC resin powder and several kinds of additives.the PVC cling film widely used for packaging and storing vegetable,cold dish,compote,raw meat,flour goods and so on in supermarket,guesthouse,restaurant,bakery and household etc.

1200-1800mm PVC Cling Film Line(Four-shaft Winder)
Model(mm)	1200	1500	1800
Screw diameter	90	100	115
L/D ratio of screw	30:1	30:1	30:1
Width of die(mm)	1700	2000	2350
Width of finished film(mm)	1200(300*4 rolls)	1500(300*5 roll)	1800(300*6 rolls)
Thickness of finished film(mm)	0.01-0.015	0.01-0.015	0.01-0.015
Max extrusion capacity(kg/h)	150-180	200-230	250-290
Design line speed(m/min)	160	200	200
Total installed power(kw)	150	220	250
Overall diamensions(LWH)	1474	167.54	1784
Weight(T)	25	30	40

Four Shaft Fully Automatic Cast PVC Cling Film Machine 1800mm

Main Features

The high efficient plasticizing screw with the advanced production technology can eliminate the generation of gem effectively.
The specifically designed T-die and extrusion forming technology realized the stability under high speed and the product's high qualitied rate.
The whole line is controlled by PLC and touch screen,and all kinds of specially-designed safety buttons are complete,convenient.

Packing & Delivery

The mormal package use pe film for packaging or pack it according to customers special request.

FAQ

Q: Can we make both manual grade and machine grade film?

A: Yes

Q: Is this machine full automatic?

A: Yes. This machine is fully automatic one.

Q: Can we also use recycled material in this machine?

A: Yes. You can use recycled material. But the more recycled material you add.

Q: Can you help us to install the machine?

A: Yes. We can arrange the technician to install the machine after it arrives in your factory.

Q: What's the payment?

A: 30% of the total amount should be paid as advance payment, 70% of total should be paid before shipment.

Q: What's the delivery date?

A:120 days since the receipt of down payment
